4mm² 2 Core Twin LSZH solar cable 1.5kV DC 100m PV56032-100M

Description

4mm² 2 Core Twin LSZH solar cable

The uploaded solar sheet covers twin LSZH cable with tinned flexible copper conductors. It lists 4, 6 and 10 mm² references and a 1.5 kV DC rating.

This listing uses the official Electra manufacturer reference PV56032 and the unique iSupply selling SKU PV56032-100M.

Applications and Cable Selection

Keep PV string calculations and battery circuits distinct. The general calculator is not a complete PV installation design tool. Confirm electrical data, connection requirements and the exact supplier supply length before purchase.

Technical Specifications

• Manufacturer: Electra Cables
• Manufacturer Part Number (MPN): PV56032
• iSupply SKU: PV56032-100M
• Cable Family: Twin LSZH solar cable
• Conductor Size: 4mm²
• Core Configuration: 2 Core
• Conductor Material: Tinned Copper
• Voltage Rating: 1.5kV DC
• Temperature Rating: 120°C
• Supply Length: 100m
• Custom Cut: Full listed roll or drum only. iSupply does not offer custom cutting at 16mm² or below.

Supply Length and Ordering

This product listing represents the documented 100m standard supply length.

Full listed roll or drum only. iSupply does not offer custom cutting at 16mm² or below.

Cable Size and Voltage Drop

Use the iSupply Voltage Calculator to compare conductor size, supply voltage, load and cable-run distance. The calculator is a voltage-drop guide and does not replace installation design, current-carrying-capacity assessment or licensed electrical advice.
